Details
Commute to work, ride to class, find new adventures in your daily routine. This flat-bar all-rounder is motivation to get your legs spinning.
KEY PERFORMANCE FACTORS:
Balanced and efficient
- Lightweight ALUXX frame, fast-rolling 700c wheels, and confident upright positioning offer a balanced, efficient ride quality.
Versatile and capable
- Powerful disc brakes and a wide range of gears help you increase your speed and tackle hills with more control.
Rugged reliability
- Puncture-resistant tires and integrated rack mounts make it easier to carry your daily essentials or load up for weekend adventures.
TECHS & FEATURES:
ALUXX ALUMINUM TECHNOLOGY
- This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.
D-FUSE TECHNOLOGY
- The D-Fuse seatpost and handlebar were designed to function as a system, absorbing road shocks, and vibrations so you can ride farther, faster.
OVERDRIVE
- Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4" lower and 1 1/8" upper for road, 1 1/2" lower and 1 1/8" upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.
Small | Medium | Large | X-Large | ||
---|---|---|---|---|---|
A | SEAT TUBE LENGTH (mm) | 430 | 485 | 535 | 585 |
B | SEAT TUBE ANGLE | 73.5° | 73.0° | 73.0° | 73.0° |
C | TOP TUBE LENGTH (mm) | 565 | 580 | 595 | 610 |
D | HEAD TUBE LENGTH (mm) | 115 | 130 | 160 | 190 |
E | HEAD TUBE ANGLE | 70.0° | 71.0° | 71.0° | 71.0° |
F | FORK RAKE (mm) | 50 | 50 | 50 | 50 |
G | TRAIL (mm) | 76 | 69.4 | 69.4 | 69.4 |
H | WHEELBASE (mm) | 1074 | 1075 | 1091 | 1107 |
I | CHAIN STAY LENGTH (mm) | 445 | 445 | 445 | 445 |
J | BOTTOM BRACKET DROP (mm) | 60 | 60 | 60 | 60 |
K | STACK (mm) | 538 | 556 | 585 | 613 |
L | REACH (mm) | 406 | 410 | 416 | 423 |
M | STAND OVER HEIGHT (mm) | 714 | 754 | 799 | 842 |
N | HANDLEBAR WIDTH (mm) | 640 | 640 | 690 | 690 |
O | STEM LENGTH (mm) | 90 | 90 | 100 | 100 |
P | CRANK LENGTH (mm) | 170 | 170 | 175 | 175 |
Q | WHEEL SIZE | 700C | 700C | 700C | 700C |
Small | 5'3" to 5'7" |
---|---|
Medium | 5'7" to 5'11" |
Large | 5'11" to 6'3" |
X-Large | 6'3" to 6'7" |
Specs
Frame | ALUXX-Grade Aluminum, disc |
---|---|
Fork | Advanced-Grade Composite, composite OverDrive steerer, disc |
Rims | Giant double wall aluminum |
Hubs | alloy, 28h |
Spokes | stainless, 14g |
Tires | Giant S-X2, puncture protect, 700x38c |
Bottom Bracket | Shimano SM-BB52 |
Crankset | Shimano MT-210, 30/46 XS:170mm, S:170mm, M:170mm, L:175mm, XL:175mm |
Shifters | Shimano Altus, 2x9 |
Front Derailleur | Shimano Acera |
Rear Derailleur | Shimano Alivio |
Cassette/Freewheel | Shimano CS-HG200, 11x36 |
Chain | KMC X9 with Missing Link |
Brakes | Tektro HD-R280, Giant MPH rotors [F]160mm, [R]160mm |
Brake Levers | Shimano |
Handlebars | Giant Sport XC, 31.8mm XS:60cm, S:64cm, M:64cm, L:68cm, XL:68cm |
Tape/Grips | Giant ErgoContact |
Stem | Giant Sport, 15-degree, 31.8mm XS:80mm, S:90mm, M:90mm, L:100mm, XL:100mm |
Seatpost | Giant D-Fuse, alloy XS:300mm, S:300mm, M:350mm, L:350mm, XL:350mm |
Saddle | Giant Sport |
Pedals | Giant Urban Fitness |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Knight Shield / Small | 04712878822474 | 2300112124 | 210000015724 |
Knight Shield / Medium | 04712878822481 | 2300112125 | 210000015725 |
Knight Shield / Large | 04712878822498 | 2300112127 | 210000015726 |
Knight Shield / X-Large | 04712878822504 | 2300112128 | 210000015727 |
