Details
GET ON THE DIRT AND RIDE YOUR WAY TO YOUR FIRST SINGLETRACK. TEMPT IS THAT FRIEND THAT OPENS A WHOLE NEW WORLD TO YOU.
KEY PERFORMANCE FACTORS
Confidence Inspiring
Perfect as your first mountain bike, the ALUXX-Grade Aluminum frame is lightweight, capable and durable.
Versatile
Tempt's performance-minded yet comfortable geometry gives it the versatility for both commutes around campus and off-road rides.
XC Control
A suspension fork offers control, comfort and stability over bumpy terrain. Depending on frame size, the fork comes with 80mm or 100mm of travel.
HIGHLIGHTS
ALUXX ALUMINUM
This performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.
FRONT SUSPENSION
80mm (XS) or 100mm (S-L) with hydraulic lockout and preload adjustment.
DISC BRAKE EQUIPPED
Powerful disc brakes for confidence and control.
2.4-INCH TIRE CLEARANCE
Enough room to run up to 2.4-inch wide tires, for added traction.
INTERNAL CABLE ROUTING
Derailleur and rear brake cables are routed internally for a weight-saving, clean look with better performance.
DROPPER SEATPOST COMPATIBLE
30.9mm seattube diameter and clean internal cable routing allows for easy dropper seatpost upgrade.
Wheel size:
- Sizes X-Small – Medium: 27.5-inch
- Sizes Small – Large: 29-inch
X-Small (27.5") | Small (27.5") | Small (29") | Medium (27.5") | Medium (29") | Large (29") | ||
---|---|---|---|---|---|---|---|
A | SEAT TUBE LENGTH (mm) | 325 | 365 | 370 | 405 | 420 | 450 |
B | SEAT TUBE ANGLE | 74.0° | 74.0° | 74.0° | 74.0° | 74.0° | 74.0° |
C | TOP TUBE LENGTH (mm) | 542 | 571 | 570 | 594 | 590 | 610 |
D | HEAD TUBE LENGTH (mm) | 95 | 100 | 90 | 110 | 95 | 105 |
E | HEAD TUBE ANGLE | 68.0° | 68.0° | 68.5° | 68.0° | 68.5° | 68.5° |
F | FORK RAKE (mm) | 40 | 42 | 51 | 42 | 51 | 51 |
G | TRAIL (mm) | 102 | 98.9 | 94.3 | 98.9 | 94.3 | 94.3 |
H | WHEELBASE (mm) | 1072 | 1104 | 1119 | 1128 | 1139 | 1160 |
I | CHAIN STAY LENGTH (mm) | 440 | 440 | 455 | 440 | 455 | 455 |
J | BOTTOM BRACKET DROP (mm) | 40 | 45 | 55 | 45 | 55 | 55 |
K | STACK (mm) | 554 | 579 | 596 | 588 | 601 | 610 |
L | REACH (mm) | 383 | 405 | 399 | 425 | 418 | 435 |
M | STAND OVER HEIGHT (mm) | 663 | 686 | 705 | 708 | 737 | 757 |
N | HANDLEBAR WIDTH (mm) | 730 | 750 | 750 | 750 | 750 | 750 |
O | STEM LENGTH (mm) | 40 | 40 | 40 | 50 | 50 | 50 |
P | CRANK LENGTH (mm) | 165 | 165 | 170 | 170 | 170 | 175 |
Q | WHEEL SIZE | 27.5" | 27.5" | 29" | 27.5" | 29" | 29" |
X-Small (27.5") | 4’11” 5’4” |
---|---|
Small (27.5") | 5’2" 5’7" |
Small (29") | 5’2" 5’7" |
Medium (27.5") | 5’5" 5’9" |
Medium (29") | 5’5" 5’9" |
Large (29") | 5’7" 5’11" |
Specs
Frame | ALUXX-Grade Aluminum, disc |
---|---|
Fork | SXC32-2 RL, air spring, QR, alloy steerer XS: 80mm travel (27.5) S: 100mm travel (27.5) / 100mm travel (29) M: 100mm travel (27.5) / 100mm travel (29) L: 100mm travel (29) |
Rims | Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width |
Hubs | Shimano, sealed bearing |
Spokes | stainless, 14g |
Tires | Kenda Booster 27.5 or 29x2.4", wire bead |
Bottom Bracket | cartridge |
Crankset | MPX-CR094S alloy, 30t XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (27.5) / 170mm travel (29) L: 175mm (29) |
Shifters | Shimano Deore M6100, 1x12 |
Rear Derailleur | Shimano Deore M6100 |
Chain | KMC X12 |
Brakes | Shimano Deore BR-MT200, hydraulic, Shimano RT-10 rotors [F]180mm, [R]160mm **some bikes may be substituted: Tektro TKD143, hydraulic [F] 180mm, [R]160mm |
Brake Levers | Shimano BL-MT200 **some bikes may be substituted: Tektro TKD143 |
Handlebars | Giant Connect Trail, 31.8mm XS: 670mm (27.5) S: 670mm (27.5) / 670mm (29) M: 750mm (27.5) / 750mm travel (29) L: 750mm (29) |
Tape/Grips | Giant Sole-O |
Stem | Giant Sport, 7-degree XS: 40mm (27.5) S: 40mm (27.5) / 40mm (29) M: 50mm (27.5) / 50mm travel (29) L: 50mm (29) |
Seatpost | Giant Sport, 30.9 XS: 300mm (27.5) S: 300mm (27.5) / 375mm (29) M: 375mm (27.5) / 375mm travel (29) L: 375mm (29) |
Saddle | Liv Sport |
Pedals | MTB caged |
Accessories & Extras | 2.4" max tire size |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Metal / Small / 27.5-inch | 04712878731318 | 2201113124 | 210000014581 |
